Belt Conveyor Belt Color Sorter for Soybean
Description:
Conveyor Belt Color Sorter for Cherry, Coffee Bean, Bean, Soybean,
Corn
Our belt color sorters are widely used for Cherry, Coffee Bean,
Bean, Soybean, Corn, Rice, Peanut, Sesame, Cashew, Walnut, Almond,
Raisin, Nuts, and Seeds sorting. we provide optical sorting
solutions for grain & food processors who demand the highest
standards of quality and safety. With a focus on precision sorting
and consistent yield, our optical sorters meet the requirements of
small, medium, and large processors.
Equipped with a high-definition 5400-pixel full-color sensor,
high-definition snapshot function, perfect restoration of the true
color of the material, 8 times magnification of photos,
ultra-high-speed linear scanning speed, improvement of the ability
to accurately identify small defects, and freshwater yellow.
| Configuration & Technology |
| Ejector | 64/126/198…../640 |
| Smart HMI | True Color 15” Industrial Human Machine Interface |
| Camera | High-resolution CCD; Industrial wide-angle low-distortion LENs;
Ultra-clear imaging |
| Intelligent Algorithm | Own proprietary industrial leading software and algorithm |
| Simultaneous Grading | Strong simultaneous color sorting+ sizing and grading capabilities |
| Consistency and Reliability | Featuring broadband cold led illumination, long-life serviceable
ejectors, Unique optical system, the MULTIFUNCTION SERIES sorter
delivers consistent sorting performance and reliable operation in
the long run |
Parameter:
| Model | Voltage | Main Power (kw) | Air Consumption (m3/min) | Throughput (t/h) | Net Weight (kg) | Dimension(LxWxH)(mm) |
| model 1 | 180~240V,50HZ | 1.4 | ≤1.2 | 1~2.5 | 615 | 1330x1660x2185 |
| model 2 | 2.0 | ≤2.0 | 2~4 | 763 | 1645x1660x2185 |
| model 3 | 2.5 | ≤2.5 | 3~6 | 915 | 2025x1660x2185 |
| model 4 | 3.0 | ≤3.0 | 3~8 | 1250 | 2355x1660x2185 |
| model 5 | 3.4 | ≤3.4 | 4~9 | 1450 | 2670x1660x2185 |
| model 6 | 3.8 | ≤3.8 | 5~10 | 1650 | 2985x1660x2195 |
| model 7 | 4.2 | ≤4.2 | 6~11 | 1850 | 3300x1660x2195 |
| model 8 | 4.8 | ≤4.8 | 8~14 | 2250 | 4100x1660x2195 |
| Note | The parameter based on test results on peanuts with around 2%
contamination; varies depending upon different input and
contamination. |
Application:
Suitable for sorting Cherry, Coffee Bean, Bean, Soybean, Corn,
Rice, peanut, sesame, cashew, walnut, almond, raisin, nuts, seeds,
grain, soybean, spices, coffee beans, snacks, plastics, minerals,
etc.
