High Definition Bean Rgb Color Sorter
Description:
RGB Color Sorter Machine utilizes High Definition full-color 5400
Pixels CCD image sensor with an advanced image processing system,
which can promote processing speed and ensure the best sorting
performance.
Color Sorter Machine Features:
1.RGB camera
RGB full-color tri-chromatic CCD image acquisition system
High camera resolution 5400-pixel identifying tiny defects up to
0.01 mm2
2.LED Lamp
Most unique intelligent LED with a cold shadowless light source and
super long life span, high lighting efficiency
3. High-Frequency Ejector
High-quality ejector with 5-10 billion ejections life low air
consumption
4.Heavy Flow Chute
Wide chute design securing high.flow capacity primary, secondary,
tertiary, quaternary sorting process mode design available
5.Dust Outlet
Accurate dust collecting position design to secure sorting room
spotlessly clean keeping high identification
6.Simplified GUI
Simplified customer-friendly GUI design highly increases the ease
of operation
7.Image Processor
Strong industry-grade digitization processor,.image acquisition and
processing in high speed; consistency of signal path and signal
reliability is secured
8.Algorithm Unit
Excellent combination of mechanical structure and tri-chromatic
control system, guarantee 99.999% accuracy and amazing·50:1
rejection rate
9.Remote Operation
Remote Monitoring + Intelligent Storage + Remote Control
Applications:
Rice, Wheat, Peanuts, Seeds, Grains, Beans and Pulses, Black
sesame, Flax seeds, Cumin seeds, Onion , Sunflower seeds, Coriander
seeds, Tomato seeds
Parameters:
| Channels | 96 |
| Throughput(t/h) | 0.8-2 |
| Power(kw) | 11 |
| Voltage (v) | 220V/50HZ 60HZ |
| Pressure (mpa) | 0.2-0.5 |
| Air consumption (m3/min) | 0.6-0.8 |
| Dimension (l*w*h,mm) | 1121x1602x1600 |
| Packing size (l*w*h,mm)1240 | 1240*1720*1820 |
| Weight (kg) | 400 |
