Mini Conveyor Belt Color Sorter
Description of conveyor belt color sorter:
Equipped with a high definition of the 5400-pixel colorful sensor,
high-definition snap image function, restore the real color of
materials, the photos can be amplified by 8 times, the
super-high-speed linear scanning speed, and improved the precision
recognition ability of small and fine points.
The intelligent compound easy-to-select algorithm system improves
the parallel analysis processing ability, creates the selection
mode, and makes the independent sorting, positive selection,
reverse selection, and multiple selections of various colors come
true, which is durable and stable, and the selection effect is more
prominent.
High brightness LED lighting system, which ensures the lighting
environment is stable and durable.
The high efficiency and stability of the transmission system, make
the belt replacement convenient, make better protection of the easy
to break and fragile materials, a wide range of use, and high
selection rate.
Scope of application:
Beans, tree nuts, grains, seeds, seasonings, crop seeds, frozen
food, dehydrated vegetables, minerals, industrial products,
traditional Chinese medicine, coffee, etc.
Data Reference:
| List of technical indicators |
| Brand | Model | Execution cell | Power | Voltage | Gas pressure | Gas consumption | Dimension(mm) | Machine weight |
| Meri | model 1 | 63 | 1.5kW | 180~240V50Hz | 0.6~0.8MPa | ≤1.2m³/min | 3780x1270x2000 | 950kg |
| model 2 | 126 | 2.0kW | <2.0m/min | 3780x1580x2000 | 1100kg |
| model 3 | 189 | 2.5kW | <2.5m/min | 3780x1890x2000 | 1250kg |
| model 4 | 252 | 3.0kW | ≤3.0m³/min | 3780x2200x2000 | 1400kg |
| model 5 | 252 | 3.0kW | ≤3.0m 3/min | 4950x1800x2400 | 2050kg |
| model 6 | 504 | 4.0kW | ≤4.0m³/min | 4950x2420x2400 | 2650kg |
|
Note: 1. Peanut is taken as an example in this parameter (impurity
content is 2%). Specific parameters vary with different materials
and impurity content. 2. If the product is updated without prior
notice, the actual situation of the machine shall prevail.
|
Performance index list
| Item | Performance description | | | Item | Performance description | | | |
| 15 inch LCD | ★ | | Pine nut | Yellowing grain, black grain, stone, and damaged grain | | | |
| Visible light ultra-clear sensor | ★ | | Pistachio | Close | | | |
| Infrared imaging system | none | | Separation of impurities | Plastics, stones, insect carcasses, glass, etc | | | |
| Infrared InGaAs sensor | none | | The service life of the spray valve | >5 billion times | | | |
| New prism splitting imaging system | none | | Visible light source life | >50000h | | | |
| The compound eye lighting system | ★ | | Power supply life of the whole machine | >50000h | | | |
| Blowout preventer | ★ | | Enhanced point to point dust collection system | big | | | |
| Geometric center positioning | ★ | | Remote protection of separation room | none | | | |
| Flexible elimination | none | | Waterproof seal IP65 | none | | | |
| Shape selection recognition | ★ | | Worry-free transmission structure | ☆ | | | |
|
| Remarks: ★ represents standard configuration; ☆represents the
optional configuration |
List of intelligent indicators
| Terminal operation | Cloud assistance | Equipment self-check | Multi-level scheme setting |
| Optional | Optional | Standard configuration | Standard configuration |
Sorting cases:
